Product family features
DEXAL interface based on DALI-2 communication
DALI-2 and D4i Certified
Always-on Auxiliary Power: 24Vdc, 125mA, 3W (Transient Peak up to 6W)
Integrated 16Vdc Bus Power Supply Based on DALI-2
Full Power at Wide Output Current Range (Constant Power)
Adjustable Output Current (AOC) with NFC
Autonomous Dimming with Five Independent Levels (Astro, Time Mode)
Dim-to-Off with Standby Power ≤ 0.5 W
Constant Lumen
End-of-life indication
Input Surge Protection: DM 6kV, CM 10kV
All-Around Protection: OTP, OVP, SCP, OLP, NLP
Support DALI Programming and NFC Programming
Integrated Power Monitoring with Accuracy up to ±5%
Enables programming via DALI cables up to 15m length
Full Compatibility with T4T(Tuner4TRONIC) and T4T Field App
Product family benefits
For Zhaga Book18 Luminaires and D4i certified incl. Parts 25x + AUX
High surge protection: up to 10 kV in protection class I or II
Lifetime: up to 100,000 h (depending on Tc temperature, max. 10 % failure rate)
DEXAL interface (with 15V current supply on DALI-2 lines - DALI Part 250)
Standardized DALI-2 communication (incl. monitoring data, energy metering)
Inventronics DALI light- and presence sensor connectable
Full compatibility with Tuner4TRONIC and T4T Field App
Enables programming via DALI cables up to 15m length
Areas of application
IP20 Design and Suitable for Outdoor Applications in Luminaires with IP>54
Suitable for luminaires of protection class I and II
Street and urban lighting
Ecodesign regulation information:
Intended for use with LED modules.
The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
