Product family features
Supply voltage: 220…240 V
Line voltage: 198…264 V
Line frequency: 0 Hz | 50 Hz | 60 Hz
Lifetime: up to 50,000 h (temperature at Tc = 80 °C, max. 10 % failure rate)
Available with output current range: up to 1,050 mA
Dimming range: 1…100 % luminous flux
Dipswitch interface
Touch DIM functionality
Corridor function
Type of protection: IP20
Low THD <10% @ full load
Low LF-ripple < 5%
Product family benefits
Safety ensured by Inventronics (SELV)
DALI-2 certified
High flexibility due to eight different output currents
Touch DIM application: easy to control via pushbutton or sensor
Easy to use in corridors and restrooms because of three-level Corridor function
Higher quality of light thanks to low output ripple current
Lifetime: up to 100,000 h (tc = 70°C with max. 10% failure rate)
Small housing for flexible luminaire designs
High-quality dimming of 1…100 %
High efficiency (up to 92.5%)
Areas of application
Offices
Shops
Hospitality
Panels
Other Indoor LED luminaries
Suitable for indoor SELV equivalent installations
Suitable for luminaires of protection classes I and II
Ecodesign regulation information:
Intended for use with LED modules.
The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
