Product family features
High color consistency: ≤ 3 SDCM
Lifetime (L80 B10): > 60,000 h (temperature at Tp = 55 °C)
Luminous flux: 1000 lm on 140 mm
Luminous flux: 2000 lm on 280 mm
Luminous flux: 4000 lm on 560 mm
Luminous flux: 3500 lm on 1120 mm
Module efficacy: up to 190 lm/W
CE and ENEC certified and UKCA marked
Dimensions match to external optics (e.g. LEDIL)
Available with CRI >80 and CRI >90
Variation of color temperatures (3000K and 4000K)
Product family benefits
Adjustable luminous flux, efficacy and lifetime
Allows very compact luminaire designs
Allows multiple module configurations in luminaires
High homogeneity thanks to LED clusters
Available in different lengths
High efficacy LED Modules
Small LED module design avoids shades, delivering great light uniformity
Can be operated with OPTOTRONIC SELV and non-SELV drivers with Uout max. < 250 V
The lengths 140 mm, 280 mm and 1120 mm can be driven with OPTOTRONIC SELV drivers
Areas of application
Industry
Office
Public and commercial buildings
Shop lighting
Ecodesign regulation information:
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
