PL-BRICK HP 2850 727 2X6
Product family
Product family features
Module efficacy: up to 186 lm/W
Average lifetime (L80 B10): up to 100,000 h (temperature up to Tc = 85 °C)
Available with color temperature: 2,200 K, 2,700 K, 3,000 K, 4,000 K, 5,700 K and 6,500 K
Available with CRI > 70 and CRI > 80
Initial color consistency: ≤ 5 SDCM
CE marked, ENEC certified
Type of protection: IP20
Product family benefits
High-performance module for outdoor and street lighting
Dimensions aligned with Zhaga book 15
Compatible with third party optics, e.g. from LEDIL
Up to 176 lm/W module efficiency for demanding lighting solutions
NTC for on-module temperature observation
Areas of application
Outdoor application
Street lighting
Industry
Highbay lighting
Area lighting
Ecodesign regulation information:
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
Find technical data and additional assets in our datasheet
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration: 26-09-2024
Product code: 4062172036214
Declaration No. in SCIP database: In work
Downloads
CAD data
Size: 294kb
CAD data 2-dim
Size: 223kb
CAD data 3-dim
Size: 266kb
Energy label, vertical
Size: 46kb
Mandatory Publications
Size: 199kb
