Product family features
Module efficacy: up to 170 lm/W with 2,700K
Module efficacy: up to 190 lm/W with 6,500K
Available module length: 62 mm, 280 mm, 560 mm
Available with luminous flux: 245 lm, 1,100 lm and 2,200 lm
Color temperature range: 2,700...6,500 K
Color rendering index Ra: >80 and >90
Initial color consistency: ≤ 3 SDCM
Average lifetime (L80 B50): up to 70,000 h (temperature at Tc = 55 °C)
Product family benefits
Tunable White by adjustable colour temperature from 2,700 K to 6,500 K
SELV or non-isolated LED Module with perfect match to Optotronic TW driver
Cut out area for shadow-free wiring
High homogeneity thanks to small LED pitch
Ecodesign regulation information:
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
