PL-BAR-G4 2200-840-560X55-HV
Product family
Product family features
Module efficacy: up to 197 lm/W
Average lifetime (L80 B10): up to 70,000 h (temperature at Tc = 55 °C)
Available module length: 1 ft/280 mm or 2 ft/560mm
Available with luminous flux: 1,156 lm, 2,312 lm and 3,572 lm
Available with color temperature: 3,000 K, 4,000 K
High initial color consistency: 3 SDCM
CE marked
Product family benefits
3-row LED module suitable for 3 x 11 optics
Cut out area for shadow-free wiring
Push-in connector for automated wiring
HV-type for serial connection
LV-type for parallel connection
Areas of application
Retail
Supermarkets
Industry
Ecodesign regulation information:
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
Find technical data and additional assets in our datasheet
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration: 26-09-2024
Primary Article Identifier: 4052899618350
Declaration No. in SCIP database: In work
Downloads
CAD data 2-dim
Size: 219kb
CAD data 3-dim
Size: 323kb
Certificates
Size: 300kb
Energy label, vertical
Size: 46kb
Mandatory Publications
Size: 980kb
Mandatory Publications
Size: 197kb
