PL-LIN-IND-Z1 2800-840 560X24
Product family
Product family features
Module efficacy: up to 193 lm/W
Available with luminous flux: 1,400 lm on 280 mm
Available with luminous flux: 2,800 lm on 560 mm
Available with color temperature: 4,000 K, 5,000 K or 6,500 K
High initial color consistency: ≤ 3 SDCM
Average lifetime (L80 B50): 100,000 h (temperature at Tc = 60 °C)
CE marked, ENEC certified
Product family benefits
LED module for robust application
Very long lifetime
Reliable system between IND LED module and Optotronic OT IND driver
Adjustable luminous flux, efficacy and lifetime
Areas of application
Industry
Ecodesign regulation information:
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
Find technical data and additional assets in our datasheet
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration: 26-09-2024
Primary Article Identifier: 4052899605879
Declaration No. in SCIP database: In work
Downloads
Declarations of conformity
Size: 197kb
Declarations of conformity
Size: 508kb
Declarations of conformity
Size: 672kb
Energy label, vertical
Size: 47kb
