Product family features
Supply voltage: 220…240 V
Line frequency: 50 Hz | 60 Hz
Line voltage: 198…264 V
Safety and performance according to IEC 61347-1, IEC 61347-2-13, IEC 62384
RI suppression according to CISPR 15
Line harmonics according to IEC 61000-3-2
Immunity according to IEC 61547
Lifetime: up to 100,000 h (temperature at Tc = -10 °C, max. 10 % failure rate)
Non-isolated drivers
Product family benefits
Versatile scope of application due to output power range of up to 65 W
Safety requirement due to overload, overtemperature, short-circuit protection
High efficiency
User flexibility with four different output currents from one driver
Areas of application
Linear and area lighting
Office, industrial and shop lighting
Suitable for luminaires of protection class I
Ecodesign regulation information:
Intended for use with LED modules.
The forward voltage of the LED light source shall be within the defined operating window of the control gear in all operating conditions including dimming if applicable.
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
