Product family features
Line frequency: 50…60 Hz
RI suppression: to EN 55015 (A1: 2007)/CISPR 15, EN 55022
Line harmonics according to EN 61000-3-2
Immunity according to EN 61547
Safety: to EN 61347
Short-circuit protection, overload protection, overtemperature protection: electronically reversible
Electrical isolation between the primary side and the secondary side
Dimmable on the leading edge (without HTN) and trailing edge
Product family benefits
Very low power loss thanks to high efficacy
Strain relief suitable for different cable types (HTM)
Suitable for space-critical installation thanks to compact functional design
Extremely compact transformer for highly space-critical installation conditions (HTN)
Protective operation throughout the entire partial-load range for long lamp life
Areas of application
Effect and accent lighting
Living rooms
Object lighting
Conference rooms
Restaurants
Recessed and surface-mounted furniture luminaires
Shop lighting
Event rooms
Ecodesign regulation information:
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
