PL-LIN-Z5 4400-830 1120X20-HV
Product family
Product family features
Module efficacy: up to 193 lm/W
Available with luminous flux: 275 lm on 70 mm
Available with luminous flux: 1,100 lm or 2,000 lm on 280 mm
Available with luminous flux: 2,000 lm, 4,000 lm on 560 mm
Available with luminous flux: 4,400 lm on 1,120 mm
Available with luminous flux: 5,500 lm on 1,400 mm
Available with color temperature: 3,000 K, 4,000 K or 6,500 K
High initial color consistency: ≤ 3 SDCM
Average lifetime (L80 B50): > 70,000 h (temperature at Tc = 50 °C)
CE marked, ENEC certified; UL listed
Product family benefits
Slim luminaire design by small and flexible form factor
High homogeneity thanks to small LED pitch
High voltage (HV) for serial connection
Low voltage (LV) for parallel connection
High voltage (HV) optimized for non-isolated, low voltage (LV) optimized for SELV operation
Adjustable luminous flux, efficacy and lifetime
Direct the light where it’s needed while using PrevaLED Linear Optics
Areas of application
Office
Industry
Ecodesign regulation information:
Separate control gear and light sources must be disposed of at certified disposal companies in accordance with Directive 2012/19/EU (WEEE) in the EU and with Waste Electrical and Electronic Equipment (WEEE) Regulations 2013 in the UK. For this purpose, collection points for recycling centres and take-back systems (CRSO) are available from retailers or private disposal companies, which accept separate control gear and light sources free of charge. In this way, raw materials are conserved and materials are recycled.
Find technical data and additional assets in our datasheet
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration: 26-09-2024
Product code: 4052899607309
Declaration No. in SCIP database: In work
